Camera Module | ELP 8MP USB Camera Module 2448P Webcam Board 75Degree Wide Angle Web Cam Module Smart Embedded Camera IMX179 4K USB Webcam Module | High-Resolution Industrial USB Camera
(-34%)
Save 35%Deliverable in 10+Business Days
Key Points
- High-resolution 8-megapixel IMX179 sensor for crisp and clear images
- 75-degree wide-angle lens for a broader field of view
- Compatible with Windows, Linux, Android, and macOS operating systems
- Supports up to 2448p resolution at 15fps and 4K resolution at 30fps
Warranty / Shipping / Returns
- Free shipping on all orders
- No additional customs duties will be charged.
- 7-day return policy applies to all products (T&C apply).
- Tracking details will be emailed, along with customer support assistance.
Product Description
The ELP 8MP USB Camera Module is a premium, high-end camera module designed for a wide range of applications, including industrial, smart embedded systems, and more. With its 75-degree wide-angle lens and 8-megapixel IMX179 sensor, this USB camera module captures crisp and clear images at up to 2448p resolution, making it perfect for use as a webcam board or industrial USB camera. Compatible with Windows, Linux, Android, and macOS operating systems, this 4K USB webcam module is versatile and easy to integrate into various projects, including those using Arduino, ESP32, and Raspberry Pi. The ELP-USB8MP02G-L75 USB Webcam is a high-level USB camera for computer house security or HD industrial applications, featuring up to 8-megapixel resolution and newly developed HD video solve camera technology.
Specification:
- Image area: 5.7mm x 4.28mm
- Performance: 3264X2448 MJPEG 15fps YUY2 2fps, 2592X1944 MJPEG 15fps YUY2 3fps, 2048X1536 MJPEG 15fps YUY2 3fps, 1600X1200 MJPEG 15fps YUY2 10fps, 1280X960 MJPEG 15fps YUY2 10fps, 1024X768 MJPEG 30fps YUY2 10fps, 800X600 MJPEG 30fps YUY2 30fps, 640X480 MJPEG 30fps YUY2 30fps, 320x240 MJPEG 30fps YUY2 30fps
- SN Ratio: 38dB
- Dynamic Range: 70dB
- Sensitivity: 1.4Vlux-sec550nm
- Mini illumination: 0.1lux
- Shutter Type: Electronic rolling shutter, Frame exposure
- Connecting Port type: USB2.0 High Speed
- Free Drive Protocol: USB Video Class (UVC)
- OTG protocol: USB2.0 OTG
- AEC Support: Yes
- AEB Support: Yes
- AGC Support: Yes
- Adjustable parameters: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, Gain, White balance, Backlight Contrast, Exposure
- Power supply: USB BUS POWER 4P-2.0mm socket
- Operating Voltage: DC5V
- Working current: 150mA-200mA
- Working temperature: -10-70
- Storage temperature: -20-85
- Board size: 38X38mm (compatible with 32X32mm)
- Operating system request: WinXP, Vista, Win7, Win8, Linux with UVC (above linux-2.6.26), MAC-OS X 10.4.8 or later, Android 4.0 or above with UVC
Specifications & Details
| SKU | BMB00WFQOTM2 |
|---|---|
| Product Dimensions | 4.2 x 3.5 x 2.7 inches |
| Item Weight | 0.018 kgs |
| Manufacturer | Ailipu Technology Co., Ltd |
| Item model number | ELP-USB8MP02G-L75 |
| Is Discontinued By Manufacturer | No |
