ETEKJOY IPC-9800ADHS-Plus | 7-inch IPS Touch Screen CCTV IP & Analog Camera Tester | Advanced POE++ WIFI 8G TF Card 8K H.265 HDMI

Product Description

The ETEKJOY IPC-9800ADHS-Plus is a premium, high-end CCTV IP and analog camera tester, expertly designed to simplify the installation and maintenance of sophisticated surveillance systems. With its stunning 7-inch IPS touch screen monitor, this advanced tester supports a wide range of formats, including HD-TVI, HD-CVI, AHD, SDI, and CVBS, ensuring seamless compatibility with various high-performance camera types. Additionally, it features enhanced POE++, WIFI, and an 8G TF card slot for superior connectivity and storage. The tester also boasts 8K H.265 decoding, HDMI in and out, and an RJ45 TDR for precise cable testing, making it an indispensable tool for professionals.

Key features of the ETEKJOY IPC-9800ADHS-Plus include IP & CVBS camera test, PTZ controller, rapid video detection, and auto-display of all network cameras. It also supports HDMI in mode, allowing for effortless conversion from analog to digital with a dual test window. Furthermore, the tester features an RJ45 cable TDR test, which enables users to examine cable pair status, length, attenuation, reflectivity, impedance, and skew. The HDMI signal input supports 1080p display image, record, and snapshot, while the CVBS loop test sends and receives color bar generator signals to check BNC cable integrity.

The ETEKJOY IPC-9800ADHS-Plus also offers traffic monitoring of the tester's LAN port, displaying real-time upload and download speeds and other essential network parameters. Users can self-update software, installing apps with Android version, such as Skype and WeChat. The tester plays 8K video files and MKV/MP4 media files, and includes an 8GB SD card with ONVIF camera test support. It also features a network PTZ controller (ONVIF), PoE++ DC48V power output, and enhanced color bar generator with PAL/NTSC multi-system color bar video generator.

Other notable features of the ETEKJOY IPC-9800ADHS-Plus include a shortcut button, drop-down menu, and support for over 30 protocols, such as PELCO-P, PELCO-D, and SAMSUNG. The tester also features audio in/out, record, and save audio, as well as an LED lamp, calculators, music players, and other application tools. With its 7.4V/5000mAh Lithium Ion Polymer Battery, the tester provides up to 10 hours of working time after 6-7 hours of charging.
